SounDigital 800.4 EVO 6 – 800W RMS 4-Channel Class D Car Audio Amplifier
Upgrade your complete car audio system with the SounDigital 800.4 EVO 6. Built on SounDigital's latest EVO 6 generation platform, this ultra-compact 4-channel Class D amplifier delivers 800 Watts RMS of clean, high-fidelity power in a remarkably small footprint.
Highly versatile, the 800.4 EVO 6 can drive four full-range door speakers independently or run in 3-channel mode (2 channels for front speakers + 1 bridged channel for a subwoofer).
EVO 6 Series Highlights & Innovations
Next-Gen Audio Architecture: Designed with modern components, redesigned power supplies, and upgraded output filters to deliver flatter frequency responses, clear highs, and deep bass.
Ultra-Compact Micro Footprint: Fits into extremely tight installation spots such as center consoles, glove boxes, under seats, or motorcycle fairings.
Smart Protection Systems: Ultra-fast electronic monitoring safeguards the amplifier against short circuits, overheating, and voltage drops.
High Efficiency & Control: Boasts 80% total efficiency and a damping factor of 200 for precise speaker cone movement and minimal electrical drain.
Technical Specifications
| Specification | Value / Details |
| 800.4 EVO 6 – 4 OHMS | |
| Power @ 4Ω | 4 x 132W RMS |
| Power @ 2Ω | 4 x 200W RMS |
| Bridged Power @ 4Ω | 2 x 400W RMS |
| Bridged Power @ 2Ω | N/A |
| GENERAL SPECIFICATIONS | |
| Frequency Response (-3dB) | 5Hz ~ 20kHz |
| Low Pass Filter (12dB/octave) | 80Hz |
| High Pass Filter (12dB/octave) | 80Hz |
| Operating Voltage | 9V ~ 16V |
| Signal-to-Noise Ratio | 93dB |
| Input Sensitivity (RCA) | 0.2V ~ 2V |
| Musical Consumption | 39A |
| Resistive Load Consumption | 78.7A |
| Total Efficiency | 80% |
| Damping Factor (@100Hz Nominal Impedance) | 200 |
| Power Cable | 10mm² (7 AWG) |
| Speaker Cable | 2 x 2.5mm² (13 AWG) |
| Recommended Fuse (Musical Use) | 40A |
| Recommended Battery (Minimum) | 60Ah |
| Width | 4.41" (11.2 cm) |
| Length | 4.21" (10.7 cm) |
| Height | 2.05" (5.2 cm) |
| Weight | 1.34 lbs (0.609 kg) |
