Description
SounDigital 5000.1 EVO 5 – 5000W RMS Monoblock Class D Car Audio Amplifier
Experience extreme sound pressure and acoustic performance with the SounDigital 5000.1 EVO 5. Engineered to deliver 5000 Watts RMS of continuous Class D power, this amplifier offers exceptional power density, thermal stability, and audio clarity.
Featuring a wide Full-Range frequency response and an integrated Bass Boost, the 5000.1 EVO 5 provides the muscle needed to drive high-excursion subwoofers or heavy-duty voice speaker walls with ease.
Key Advantages & Innovations:
High Efficiency & Control: Boasts an 86% total efficiency rating and a damping factor exceeding 2000, ensuring maximum punch, control, and minimal electrical strain on your vehicle.
SounDigital Smart Start (SSS): Easily connect to factory OEM head units using the High-Level inputs. The amplifier detects audio signal and automatically powers on/off without a remote wire.
Integrated Bass Boost: Fine-tune low-end response with an adjustable bass boost circuit offering 0dB to 12dB of gain centered at 50Hz.
Heavy-Gauge Connections: 0 AWG (50mm²) power block terminals ensure maximum current delivery and minimal voltage drop under full load.
Technical Specifications
| Specification | Value / Details |
| 5000.1 EVO 5 – 1 OHM | |
| Power @ 1Ω | 1 x 5000W RMS |
| Power @ 2Ω | 1 x 3300W RMS |
| Power @ 4Ω | 1 x 2178W RMS |
| 5000.1 EVO 5 – 2 OHMS | |
| Power @ 1Ω | N/A |
| Power @ 2Ω | 1 x 5000W RMS |
| Power @ 4Ω | 1 x 3300W RMS |
| GENERAL SPECIFICATIONS | |
| Frequency Response (-3dB) | 5Hz ~ 20kHz |
| Subsonic Filter (12dB/octave) | 5Hz ~ 80Hz |
| Low Pass Filter (12dB/octave) | 50Hz ~ 20kHz |
| Bass Boost | 0dB ~ 12dB @ 50Hz |
| Operating Voltage | 8V ~ 16V |
| Signal-to-Noise Ratio | 90dB |
| Input Sensitivity (RCA) | 0.2V ~ 2V |
| Input Sensitivity (High Level) | 1.5V ~ 15V |
| Musical Consumption | 230A |
| Max Consumption | 461A |
| Total Efficiency | 86% |
| Damping Factor (@100Hz Nominal Impedance) | >2000 |
| Power Cable | 50mm² (0 AWG) |
| Audio Output Cable | 1Ω: 2 x 10mm² (7 AWG) | 2Ω: 2 x 6mm² (9 AWG) |
| Recommended Fuse (Musical) | 250A |
| Recommended Battery (Minimum for Musical Use) | 250Ah |
| Width | 7.09" (18 cm) |
| Length | 9.84" (25 cm) |
| Height | 2.49" (6.32 cm) |
| Weight | 6.83 lbs (3.10 kg) |
EVO 5 Series Highlights & Innovations
-
Advanced Audio Architecture: Built with top-tier components and intelligent circuit design, the EVO 5 lineup features redesigned power supplies, output filters, and audio processing circuitry. This delivers flatter, more extended frequency responses, precise highs, and deep, defined bass notes.
-
Next-Gen Reliability & Protection: Engineered for extreme durability, the EVO 5 platform offers industry-leading thermal control and high resistance to vehicle vibration. Modernized smart protection systems act instantly to safeguard the amplifier against speaker shorts, wiring issues, and power supply faults.
-
Clean & Smart Installation Solutions:
-
Heavy-Duty Allen Screw Terminals: Solid connector blocks with steel Allen screws ensure maximum wire clamping force and seamless power transfer.
-
Concealed Mounting Screws: Features removable cover plates over the mounting screw holes to deliver a sleek, clean, and professional finish after installation.
-
SounDigital Smart Start (SSS): High-Level OEM input detects audio signal from factory head units and powers the amplifier on/off automatically—no remote turn-on wire or RCA converter required.
-
