Description
The DIGITAL BASS line was developed for car audio enthusiasts seeking maximum low-frequency performance.
Its frequency response of 5Hz to 250Hz offers quality and definition in the lower ranges, delivering powerful, intense bass.
TECHNICAL SPECIFICATIONS
| CHARACTERISTICS | DB8000 – 1 OHM |
|---|---|
| Number of Channels | 1 |
| RMS Power | 8000W |
| RMS Power at 1 Ohm 12.6V | 8.500W |
| RMS Power at 2 Ohm 12.6V | 5.000W |
| RMS Power at 1 Ohm 13.8V | 9.400W |
| RMS Power at 2 Ohm 13.8V | 5.375W |
| RMS Power at 1 Ohm 14.4V | 9.630W |
| RMS Power at 2 Ohm 14.4V | 5.400W |
| Supply Voltage | 9V ~ 16V DC |
| Frequency Response | 5Hz ~ 250Hz @ 1 Ohm |
| Crossover Low Pass | 35Hz ~ 250Hz |
| Signal to Noise | >90dB |
| Input Sensitivity | 200mV |
| Input Impedance | 19K Ohms |
| Impedance Output | 1 Ohm |
| Consumption with Signal Musical | 409A |
| Consumption with Signal Bass | 818A |
| Dimensions (H x W x D) mm | 78 x 455,5 x 231,5 mm |
| Weight Kg | 6,7 Kg |
